CEP-2242
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Audio Products / Alarms, Buzzers, and Sirens
Description
AUDIO PIEZO INDICATOR 3-16V TH
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.2264
≥1 USD $2.2264
≥10 USD $1.8436
≥100 USD $1.70192
≥500 USD $1.59896
≥1000 USD $1.49996
≥3000 USD $1.388314
Inventory: 1361
Minimum: 1
-
+
Technical Details
Compliance
Ratings Washable
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.319 8.10mm
Height 8.1mm
Diameter 13.7mm
Technical
Driver Circuitry Indicator, Internally Driven
Sound Pressure Level (SPL) 70dB @ 12V, 30cm
Port Location Top
Washable Yes
Self Resonant Frequency 4.1kHz
Voltage Range 3V~16V
Current - Supply 7mA
Input Type DC
Operating Mode Single Tone
Operating Supply Current 7mA
Frequency 4.1kHz
Technology Piezo
Voltage - Rated 12V
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.539Dia 13.70mm
Series CEP
Published 2011
Packaging Tray
Operating Temperature -20°C~70°C
Physical
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
