CEP-1160
RoHS
/
Package Radial
Category Audio Products / Alarms, Buzzers, and Sirens
Description
AUDIO PIEZO TRANSDUCER 20V TH
PDF
/
Inventory: 9213
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Technical
Operating Temperature -20°C~60°C
Packaging Bulk
Published 2006
Series CEP
Size / Dimension 0.551Dia 14.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Voltage - Rated 10V
Capacitance 17nF
Technology Piezo
Operating Supply Current 10mA
Operating Mode Single Tone
Input Type Peak-Peak Signal
Voltage Range 20V Max
Self Resonant Frequency 4kHz
Port Location Top
Sound Pressure Level (SPL) 76dB @ 10V, 10cm
Driver Circuitry Transducer, Externally Driven
Dimensions
Diameter 14mm
Height 8mm
Height Seated (Max) 0.315 8.00mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
