CEP-1116
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Audio Products / Alarms, Buzzers, and Sirens
Description
AUDIO PIEZO TRANSDUCER 30V TH
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2144
≥1 USD $1.2144
≥10 USD $1.00848
≥100 USD $0.931744
≥500 USD $0.913
Inventory: 1167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Technical
Operating Temperature -30°C~85°C
Packaging Tray
Published 2011
Series CEP
Size / Dimension 1.181Dia 30.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Voltage - Rated 10V
Capacitance 28nF
Technology Piezo
Operating Supply Current 8mA
Operating Mode Single Tone
Input Type Peak-Peak Signal
Voltage Range 30V Max
Self Resonant Frequency 2kHz
Washable No
Port Location Top
Sound Pressure Level (SPL) 90dB @ 10V, 10cm
Driver Circuitry Transducer, Externally Driven
Dimensions
Diameter 30mm
Height 10.5mm
Height Seated (Max) 0.413 10.50mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
