D75K15KE
RoHS
RoHS compliant
RoHS compliantPackage Radial, 3 Lead, Tubular
Category Potentiometers, Variable Resistors / Adjustable Power Resistor
Description
Wirewound Resistors 75watt 15K 10% Tubular Ceramic
PDF
/
Inventory: 2353
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 6.000 152.40mm
Diameter 0.563 OD 0.313 ID 14.30mmx7.94mm
Technical
Ganging Number 1
Adjustment Type Slide
Resistor Type POTENTIOMETER
Technology WIRE WOUND
Max Power Dissipation 75W
Power Rating 75W
Subcategory Variable Resistors
HTS Code 8533.39.00.80
Additional Feature FLAMEPROOF
Voltage - Rated 2.625kV
Min Operating Temperature 25°C
Max Operating Temperature 350°C
Resistance 15kOhm
Temperature Coefficient 260 ppm/°C
ECCN Code EAR99
Termination Solder Lug
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±10%
Series Dividohm?210
Published 2015
Packaging Bulk
Physical
Terminal Shape LUG
Package / Case Radial, 3 Lead, Tubular
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 10 Weeks
