D50K75R
RoHS
/
Package Radial, 3 Lead, Tubular
Category Potentiometers, Variable Resistors / Adjustable Power Resistor
Description
Wirewound Resistors 50watt 75ohm 10% Tubular Ceramic
PDF
/
Inventory: 8349
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 4.000 101.60mm
Diameter 0.563 OD 0.313 ID 14.30mmx7.94mm
Technical
Ganging Number 1
Adjustment Type Slide
Resistor Type POTENTIOMETER
Construction All-Welded
Technology WIRE WOUND
Max Power Dissipation 50W
Voltage - Rated DC 1.62kV
Power Rating 50W
Subcategory Variable Resistors
HTS Code 8533.39.00.80
Voltage - Rated 1.625kV
Min Operating Temperature 25°C
Max Operating Temperature 350°C
Terminal Finish Tin/Lead (Sn/Pb)
Resistance 75Ohm
Temperature Coefficient 260 ppm/°C
ECCN Code EAR99
Termination Solder Lug
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±10%
Series Dividohm?210
Published 2012
Packaging Bulk
Physical
Material Ceramic
Number of Pins 2
Terminal Shape LUG
Package / Case Radial, 3 Lead, Tubular
Mounting Type Chassis Mount
Mount Bolt, Chassis Mount
Supply Chain
Factory Lead Time 10 Weeks
