D25K100
RoHS
/
Package Radial, 3 Lead, Tubular
Category Potentiometers, Variable Resistors / Adjustable Power Resistor
Description
Wirewound Resistors 25watt 100ohm 10% Tubular Ceramic
PDF
/
Inventory: 3099
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Bolt, Chassis Mount
Mounting Type Chassis Mount
Package / Case Radial, 3 Lead, Tubular
Terminal Shape LUG
Number of Pins 2
Material Ceramic
Technical
Packaging Bulk
Published 2008
Series Dividohm?210
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Solder Lug
ECCN Code EAR99
Temperature Coefficient 260 ppm/°C
Resistance 100Ohm
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 350°C
Min Operating Temperature 25°C
Composition Wirewound
Voltage - Rated 625V
HTS Code 8533.39.00.80
Subcategory Variable Resistors
Power Rating 25W
Voltage - Rated DC 625V
Max Power Dissipation 25W
Technology WIRE WOUND
Depth 14.3mm
Construction All-Welded
Resistor Type POTENTIOMETER
Adjustment Type Slide
Ganging Number 1
Dimensions
Diameter 0.563 OD 0.313 ID 14.30mmx7.94mm
Length 2.000 50.80mm
Compliance
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
