D100K5R0

Ohmite
RoHS
/
Package Radial, 3 Lead, Tubular
Category Potentiometers, Variable Resistors / Adjustable Power Resistor
Description Wirewound Resistors 100watt 5ohm 10% Tubular Ceramic
PDF
/
Inventory: 7630
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Termination Solder Lug
ECCN Code EAR99
Temperature Coefficient 260 ppm/°C
Resistance 5Ohm
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 350°C
Min Operating Temperature 25°C
Composition Wirewound
Voltage - Rated 2.845kV
HTS Code 8533.39.00.80
Subcategory Variable Resistors
Power Rating 100W
Voltage - Rated DC 2.84kV
Max Power Dissipation 100W
Technology WIRE WOUND
Construction All-Welded
Resistor Type POTENTIOMETER
Adjustment Type Slide
Ganging Number 1
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±10%
Series Dividohm?210
Published 2014
Packaging Bulk

Dimensions

Diameter 0.752 OD 0.500 ID 19.10mmx12.70mm
Length 6.500 165.10mm

Compliance

REACH SVHC Unknown
RoHS Status Non-RoHS Compliant

Physical

Material Ceramic
Number of Pins 2
Terminal Shape LUG
Package / Case Radial, 3 Lead, Tubular
Mounting Type Chassis Mount
Mount Bolt, Chassis Mount

Supply Chain

Factory Lead Time 10 Weeks
