D100K500
RoHS
/
Package Radial, 3 Lead, Tubular
Category Potentiometers, Variable Resistors / Adjustable Power Resistor
Description
Wirewound Resistors 100watt 500ohm 10% Tubular Ceramic
PDF
/
Inventory: 4171
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC Unknown
Dimensions
Length 6.500 165.10mm
Diameter 0.752 OD 0.500 ID 19.10mmx12.70mm
Technical
Ganging Number 1
Adjustment Type Slide
Resistor Type POTENTIOMETER
Construction All-Welded
Depth 19.1mm
Technology WIRE WOUND
Max Power Dissipation 100W
Voltage - Rated DC 2.84kV
Power Rating 100W
Subcategory Variable Resistors
HTS Code 8533.39.00.80
Voltage - Rated 2.845kV
Composition Wirewound
Min Operating Temperature 25°C
Max Operating Temperature 350°C
Terminal Finish Tin/Lead (Sn/Pb)
Resistance 500Ohm
Temperature Coefficient 260 ppm/°C
ECCN Code EAR99
Termination Solder Lug
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±10%
Series Dividohm?210
Published 2014
Packaging Bulk
Physical
Number of Pins 2
Terminal Shape LUG
Package / Case Radial, 3 Lead, Tubular
Mounting Type Chassis Mount
Mount Bolt, Chassis Mount
Supply Chain
Factory Lead Time 10 Weeks
