D100K25R
RoHS
/
Package Radial, 3 Lead, Tubular
Category Potentiometers, Variable Resistors / Adjustable Power Resistor
Description
Wirewound Resistors 100watt 25ohm 10% Tubular Ceramic
PDF
/
Inventory: 2896
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Bolt, Chassis Mount
Mounting Type Chassis Mount
Package / Case Radial, 3 Lead, Tubular
Terminal Shape LUG
Material Ceramic
Technical
Packaging Bulk
Published 2015
Series Dividohm?210
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Solder Lug
ECCN Code EAR99
Temperature Coefficient 260 ppm/°C
Resistance 25Ohm
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 350°C
Min Operating Temperature 25°C
Voltage - Rated 2.845kV
HTS Code 8533.39.00.80
Subcategory Variable Resistors
Power Rating 100W
Voltage - Rated DC 2.84kV
Max Power Dissipation 100W
Technology WIRE WOUND
Construction All-Welded
Resistor Type POTENTIOMETER
Adjustment Type Slide
Ganging Number 1
Dimensions
Diameter 0.752 OD 0.500 ID 19.10mmx12.70mm
Length 6.500 165.10mm
Compliance
RoHS Status Non-RoHS Compliant
