D100K100E
RoHS
RoHS compliant
RoHS compliantPackage Radial, 3 Lead, Tubular
Category Potentiometers, Variable Resistors / Adjustable Power Resistor
Description
RESISTOR POWER ADJ 100 OHM 100W
PDF
/
Buying Options
Total Price: USD $27.22
Unit Price: USD $27.2184
≥1 USD $27.2184
≥10 USD $22.49368
≥100 USD $21.491008
≥500 USD $20.416704
≥1000 USD $18.840624
≥3000 USD $18.625693
Inventory: 37
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Length 6.500 165.10mm
Diameter 0.752 OD 0.500 ID 19.10mmx12.70mm
Technical
Ganging Number 1
Adjustment Type Slide
Voltage - Rated AC 100V
Resistor Type POTENTIOMETER
Construction All-Welded
Depth 19.1mm
Technology WIRE WOUND
Max Power Dissipation 100W
Voltage - Rated DC 2.845kV
Power Rating 100W
Subcategory Variable Resistors
HTS Code 8533.39.00.80
Composition Wirewound
Min Operating Temperature 25°C
Max Operating Temperature 350°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Resistance 100Ohm
Temperature Coefficient 260 ppm/°C
ECCN Code EAR99
Termination Solder Lug
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±10%
Series Dividohm?210
Published 2005
Packaging Bulk
Physical
Number of Pins 2
Terminal Shape LUG
Package / Case Radial, 3 Lead, Tubular
Mounting Type Chassis Mount
Mount Bolt, Chassis Mount
Supply Chain
Factory Lead Time 10 Weeks
