LCQT-SOIC14W

Aries Electronics
RoHS
/
Package SOIC
Category Prototyping, Fabrication Products / Adapter, Breakout Boards
Description Correct-A-Chip? SMD to DIP FR4Epoxy Glass 14 Adapter 5.9944mm 125C
PDF
/
Buying Options
Total Price: USD $3.98
Unit Price: USD $3.9776
≥1 USD $3.9776
≥10 USD $3.61152
≥100 USD $3.420613
≥500 USD $3.341026
≥1000 USD $3.181886
≥3000 USD $2.784162
Inventory: 244
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Dimensions

Board Thickness 0.062 1.57mm 1/16

Technical

Proto Board Type SMD to DIP
Row Spacing 15.24 mm
Lead Length 5.9944mm
Pitch 0.050 1.27mm
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 14
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.700Lx0.700W 17.78mmx17.78mm
Series Correct-A-Chip?
Published 2014

Physical

Package Accepted SOIC
Housing Material Polyester
Material FR4 Epoxy Glass
Number of Pins 14
Package / Case SOIC
Mount Through Hole

Supply Chain

Factory Lead Time 5 Weeks
