RoHS
RoHS RoHS compliant
Package Module
Category Power Supplies - Board Mount / Accessories
Description BOOSTER(PT4474) 20A 24VIN HRZ
PDF
/
Inventory: 1948
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case Module
Surface Mount NO

Technical

Series PT4470
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 26
ECCN Code EAR99
Technology HYBRID
Terminal Position SINGLE
Terminal Form THROUGH-HOLE
Peak Reflow Temperature (Cel) 215
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT4494
Pin Count 26
JESD-30 Code R-MSMA-T26
Number of Outputs 1
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Input Voltage-Nom 24V
Temperature Grade INDUSTRIAL
Trim/Adjustable Output YES
Accessory Type Booster
Input Voltage (Max) 36V

Dimensions

Height 12.7mm
Length 91.7mm
Width 38.1mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
