AB2
RoHS
/
Package /
Category Development Boards, Kits, Programmers / Accessories
Description
DAUGHTERCARD F020/040/060/120TB
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.4978
≥1 USD $0.4978
≥10 USD $0.4085
≥100 USD $0.39615
≥500 USD $0.38285
≥1000 USD $0.3705
Inventory: 7808
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Operating Frequency-Min 10MHz
Operating Frequency-Max 945MHz
Frequency Adjustment-Mechanical NO
Supply Current-Max 121mA
Accessory Type Interface Board
Oscillator Type LVPECL
Supply Voltage-Min (Vsup) 2.97V
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.63V
Symmetry-Max 55/45%
Fall Time-Max 0.35ns
Rise Time-Max 0.35ns
Operating Frequency 25MHz
Operating Temperature (Min) -40°C
Physical Dimension 7.0mm x 5.0mm x 1.85mm
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Frequency Stability 20%
Supply Voltage 3.3V
Subcategory Other Oscillators
Additional Feature TRAY
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Physical
Mounting Feature SURFACE MOUNT
Surface Mount YES
