6JBLK
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Accessories - Caps
Description
CAP PUSHBUTTON SQUARE BLACK
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.1496
≥1 USD $0.1496
≥10 USD $0.1452
≥100 USD $0.141856
≥500 USD $0.13904
≥1000 USD $0.13596
≥3000 USD $0.129958
Inventory: 5451
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 8mm
Length 8mm
Height 3.8mm
Technical
PCB Hole Count 4
Contact (DC) Max Rating R Load 0.05A@12VDC
Size 8.00mm Lx8.00mm Wx5.00mm H
Switch Type Pushbutton
Illumination Non-Illuminated
Electrical Life 100000 Cycle(s)
Dielectric Withstanding Voltage 250VAC V
Termination Type SOLDER
Contact Voltage(DC)-Max 12V
Contact Current(DC)-Max 0.05A
Insulation Resistance 100000000Ohm
Contact Resistance 0.1mOhm
Switch Function SPST
Operating Temperature (Min) -20°C
Operating Temperature (Max) 70°C
Color Black
Terminal Finish Silver (Ag)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Published 2003
Physical
End Contact Plating SILVER
End Contact Material PHOSPHOR BRONZE
Terminal Material COPPER ALLOY
Center Contact Material PHOSPHOR BRONZE
Center Contact Plating SILVER
Actuator Material POLYBUTYLENE TEREPHTHALATE
Shape Square
Housing Material POLYBUTYLENE TEREPHTHALATE
Mounting Feature THROUGH HOLE-STRAIGHT
Surface Mount NO
Mounting Type Snap Fit
Supply Chain
Factory Lead Time 11 Weeks
