1CBLU
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Accessories - Caps
Description
Switch Accessories 9 X 5MM RECT CAP BLU
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.216865
≥1 USD $0.216865
≥10 USD $0.190924
≥100 USD $0.179818
≥500 USD $0.13205
≥1000 USD $0.1273
Inventory: 1160
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 5.08mm
Height 9.09mm
Technical
Switch Action MOMENTARY
Contact Voltage(AC)-Max 250V
Contact (DC) Max Rating R Load 6A@24VDC
Contact (AC) Max Rating R Load 5A@250VAC
Contact Current(AC)-Max 5A
Size 9.40mm Lx4.50mm Wx9.00mm H
Switch Type Pushbutton
Illumination Non-Illuminated
Electrical Life 50000 Cycle(s)
Termination Type SOLDER LUG
Contact Voltage(DC)-Max 24V
Contact Current(DC)-Max 6A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.1mOhm
Switch Function SPDT
Operating Temperature (Min) -20°C
Operating Temperature (Max) 55°C
Color Blue
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2002
Physical
End Contact Plating SILVER
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Center Contact Plating SILVER
Shape Rectangular, Concave
Mounting Feature PANEL MOUNT
Surface Mount NO
Mounting Type Snap Fit
Supply Chain
Factory Lead Time 11 Weeks
