HEDS-5120#C14
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Sensors, Transducers / Accessories
Description
BROADCOM LIMITED HEDS-5120#C14 Metal CW,28mm,2Ch,100CPR,5mm
PDF
/
Buying Options
Total Price: USD $13.44
Unit Price: USD $13.4376
≥1 USD $13.4376
≥10 USD $13.25016
≥100 USD $13.142976
Inventory: 248
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Pulses per Revolution 100
Built in Switch No
Optoelectronic Device Type OPTICAL CODE WHEELS
Accessory Type Codewheel
Number of Channels 2
Operating Supply Voltage 5V
Frequency 100kHz
Subcategory Optical Position Encoders
HTS Code 8543.90.88.80
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series HEDS
Published 2004
Physical
Mounting Feature SURFACE MOUNT
Surface Mount YES
Package / Case Metal
Supply Chain
Factory Lead Time 12 Weeks
