FDA2-17255QBKT3D-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 172X55MM 230VAC TERM
PDF
/
Inventory: 7265
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP56, Water Resistant
RoHS Status ROHS3 Compliant
Technical
Static Pressure 0.531 in H2O (132.3 Pa)
Noise 61.0 dB(A)
Air Flow 240.0 CFM (6.72m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3100 RPM
Lifetime @ Temp 100000 Hrs @ 25°C
Approval Agency CE, cURus, TUV
Current Rating 120mA
Ingress Protection IP56M - Dust Protected, Water Resistant
Max Power Dissipation 27W
Current Rating (Amps) 0.120A
Voltage - Rated 230VAC
Power (Watts) 27.00W
Termination 2 Terminals
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Rectangular/Rounded - 172mm Lx151mm H
Series HPLC, FDA2-17255
Operating Temperature -4~158°F -20°C~70°C
Physical
Material - Blade Plastic
Material - Frame Aluminum
Weight 1.8lbs 816.5g
Supply Chain
Factory Lead Time 16 Weeks
