FDA2-17255NBHT4F
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / AC Fans
Description
AC Fans AC FAN 172x55mm Ball 115VAC TERM
PDF
/
Buying Options
Total Price: USD $48.93
Unit Price: USD $48.925024
≥1 USD $48.925024
≥10 USD $46.155685
≥100 USD $43.543092
≥500 USD $41.078393
≥1000 USD $38.753199
Inventory: 1244
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 55.00mm
Length 172mm
Height 151mm
Technical
Static Pressure 0.531 in H2O (132.3 Pa)
Noise 61.0 dB(A)
Air Flow 240.0 CFM (6.72m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3100 RPM
Lifetime @ Temp 50000 Hrs @ 25°C
Approval Agency CE, cURus, TUV
Current Rating 210mA
Max Power Dissipation 25W
Current Rating (Amps) 0.210A
Power Rating 27W
Voltage - Rated 115VAC
Power (Watts) 25.00W
Min Operating Temperature -4°C
Max Operating Temperature 158°C
Termination 2 Terminals
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Rectangular/Rounded - 172mm Lx151mm H
Series HPLC, FDA2-17255
Published 2014
Operating Temperature -4~158°F -20°C~70°C
Physical
Material - Blade Steel
Material - Frame Aluminum
Weight 1.8lbs 816.5g
Housing Material Plastic
Package / Case Axial
Supply Chain
Factory Lead Time 17 Weeks
