FDA2-17251QBKT3F
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / AC Fans
Description
AC Fans AC FAN 172x51mm Ball 230VAC TERM
PDF
/
Buying Options
Total Price: USD $30.84
Unit Price: USD $30.844
≥1 USD $30.844
≥10 USD $28.17056
≥100 USD $27.10048
≥500 USD $25.3176
≥1000 USD $23.356432
≥3000 USD $22.999821
Inventory: 83
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Package / Case Axial
Housing Material Aluminium
Weight 1.9lbs 861.8g
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature -4~158°F -20°C~70°C
Packaging Bulk
Published 2014
Series HPLC, FDA2-17251
Size / Dimension Rectangular/Rounded - 172mm Lx151mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Terminals
Power (Watts) 27.00W
Voltage - Rated 230VAC
Power Rating 27W
Current Rating (Amps) 0.120A
Max Power Dissipation 27W
Current Rating 120mA
Approval Agency CE, cURus, TUV
Lifetime @ Temp 50000 Hrs @ 25°C
RPM 3300 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 275.0 CFM (7.70m3/min)
Noise 60.0 dB(A)
Static Pressure 0.768 in H2O (191.3 Pa)
Dimensions
Height 151mm
Compliance
RoHS Status ROHS3 Compliant
