FDA2-17251NBHW4F
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / AC Fans
Description
AC Fans AC FAN 172x51mm Ball 115VAC WIRE
PDF
/
Buying Options
Total Price: USD $36.46
Unit Price: USD $36.4584
≥1 USD $36.4584
Inventory: 138
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 151mm
Technical
Static Pressure 0.610 in H2O (151.9 Pa)
Noise 59.0 dB(A)
Air Flow 250.0 CFM (7.00m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3100 RPM
Lifetime @ Temp 50000 Hrs @ 25°C
Approval Agency CE, cURus, TUV
Current Rating 210mA
Max Power Dissipation 25W
Current Rating (Amps) 0.210A
Power Rating 27W
Voltage - Rated 115VAC
Power (Watts) 25.00W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Rectangular/Rounded - 172mm Lx151mm H
Series HPLC, FDA2-17251
Published 2014
Operating Temperature -4~158°F -20°C~70°C
Physical
Material - Blade Steel
Material - Frame Aluminum
Weight 2lbs 907.2g
Housing Material Plastic
Package / Case Axial
Supply Chain
Factory Lead Time 17 Weeks
