FDA2-17238QBHW3D

Qualtek
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / AC Fans
Description FAN AXIAL 172X38.5MM 230VAC WIRE
PDF
/
Inventory: 6124
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings IP56, Water Resistant
RoHS Status ROHS3 Compliant

Technical

Static Pressure 0.571 in H2O (142.2 Pa)
Noise 59.0 dB(A)
Air Flow 240.0 CFM (6.72m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3100 RPM
Lifetime @ Temp 50000 Hrs @ 25°C
Approval Agency CE, cURus, TUV
Current Rating 120mA
Ingress Protection IP56M - Dust Protected, Water Resistant
Max Power Dissipation 27W
Current Rating (Amps) 0.120A
Voltage - Rated 230VAC
Power (Watts) 27.00W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Rectangular/Rounded - 172mm Lx151mm H
Series HPLC, FDA2-17238
Published 2014
Operating Temperature -4~158°F -20°C~70°C

Physical

Material - Blade Plastic
Material - Frame Aluminum
Weight 1.8lbs 816.5g

Supply Chain

Factory Lead Time 16 Weeks
