UF25GC23-BWHNR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 254X89MM 230VAC IP55
PDF
/
Inventory: 4003
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Weight 4.1lbs 1.9kg
Material - Frame Aluminum
Material - Blade Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -40~158°F -40°C~70°C
Published 2014
Series UF25GC
Size / Dimension Round - 254mm Dia
Feature Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power (Watts) 33.00W
Voltage - Rated 230VAC
Current Rating (Amps) 0.140A
Ingress Protection IP55 - Dust Protected, Water Resistant
Approval Agency CE, cUL, TUV, UL
RPM 1650 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 550.0 CFM (15.40m3/min)
Noise 55.0 dB(A)
Static Pressure 0.400 in H2O (99.6 Pa)
Dimensions
Width 89.00mm
Compliance
RoHS Status RoHS Compliant
