A2D250-AA06-44
RoHS
/
Package Axial
Category Fans, Thermal Management / AC Fans
Description
EBM PAPST A2D250-AA06-44 AXIAL FAN
PDF
/
Buying Options
Total Price: USD $268.3
Unit Price: USD $268.3032
≥1 USD $268.3032
≥10 USD $247.1216
≥100 USD $231.235488
Inventory: 51
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Diameter 250mm
Technical
Static Pressure 0.502 in H2O (125.0 Pa)
Power Consumption 160W
Air Flow 1089 CFM
Fan Type Tubeaxial, 3 Phase
Bearing Type Ball
RPM 2900 RPM
Min Supply Voltage 230V
Max Supply Voltage 400V
Approval Agency CE
Voltage - Rated AC 578mV
Frequency 60Hz
Current Rating 260mA
Ingress Protection IP44
Current Rating (Amps) 0.220/0.380A
Power Rating 160W
Voltage - Rated 266/460VAC
Power (Watts) 150W
Termination 7 Wire Leads - Ring Terminal (1), Wire Leads with Splice Terminals (6)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Dual Voltage
Size / Dimension Round - 250mm Dia
Series A2D250
Operating Temperature -13~149°F -25°C~65°C
Physical
Material - Blade Steel
Weight 2.3kg
Material Metal
Package / Case Axial
Supply Chain
Factory Lead Time 20 Weeks
