8830A
RoHS
/
Package Axial
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 80X38MM 115VAC TERM
PDF
/
Inventory: 1098
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 80mm
Technical
Thermal Support Device Type AC FAN
Noise 29.0 dB(A)
Air Flow 20.0 CFM (0.560m3/min)
Fan Type Tubeaxial
Bearing Type Sintec
RPM 1950 RPM
Lifetime @ Temp 62500 Hrs @ 40°C
Operating Supply Voltage 115V
Approval Agency CE, CSA, UL, VDE
Frequency 60Hz
Max Power Dissipation 8W
Power Rating 8W
Voltage - Rated 115VAC
Power (Watts) 8.00W
Termination 2 Terminals
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension Square - 80mm Lx80mm H
Series 8000A
Operating Temperature 14~176°F -10°C~80°C
Physical
Material - Frame Metal
Weight 1.1lbs 499.0g
Package / Case Axial
Mount Flanges
