4656ZW
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / AC Fans
Description
AC Fan Ball Bearing 230V 18W 50Hz/60Hz 106CFM 45dB Flange Mount
PDF
/
Inventory: 5338
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 119mm
Technical
Thermal Support Device Type AC FAN
Noise 40.0 dB(A)
Power Consumption 19W
Air Flow 94.2 CFM (2.64m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2650 RPM
Cable Length 310mm
Lifetime @ Temp 37500 Hrs @ 40°C
Operating Supply Voltage 230V
Voltage - Rated AC 230V
Frequency 50Hz
Depth 119mm
Max Power Dissipation 19W
Power Rating 19W
Voltage - Rated 230VAC
Power (Watts) 19.00W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 119mm Lx119mm H
Series 4000Z
Operating Temperature -40~167°F -40°C~75°C
Physical
Weight 1.2lbs 544.3g
Material Metal
Package / Case Axial
Mount Flanges
Supply Chain
Factory Lead Time 20 Weeks
