4606TZ
RoHS
/
Package Axial
Category Fans, Thermal Management / AC Fans
Description
AC Fans Axial, 108x37mm 115VAC, Ball
PDF
/
Buying Options
Total Price: USD $47.93
Unit Price: USD $47.933764
≥1 USD $47.933764
≥10 USD $45.22053
≥100 USD $42.660881
≥500 USD $40.246109
≥1000 USD $37.968027
Inventory: 5907
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Plating Tin
Mount Flanges
Package / Case Axial
Weight 0.948lb 430.01g
Material - Frame Metal
Technical
Operating Temperature -40~167°F -40°C~75°C
Series 4600TZ
Size / Dimension Round - 108mm Dia
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power (Watts) 18.00W
Voltage - Rated 115VAC
Power Rating 18W
Max Power Dissipation 18W
Frequency 60Hz
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 40000 Hrs @ 40°C
RPM 2950 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 82.4 CFM (2.31m3/min)
Noise 45.0 dB(A)
Thermal Support Device Type AC FAN
Dimensions
Diameter 108mm
Height 37mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
