4606N
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 119X38MM 115VAC TERM
PDF
/
Buying Options
Total Price: USD $44.79
Unit Price: USD $44.792
≥1 USD $44.792
≥10 USD $40.52928
≥100 USD $37.86288
≥500 USD $37.3296
≥1000 USD $34.39656
≥3000 USD $34.12992
Inventory: 809
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Flanges
Package / Case Axial
Material Metal
Weight 1.2lbs 544.3g
Technical
Operating Temperature -40~194°F -40°C~90°C
Series 4000N
Size / Dimension Square - 119mm Lx119mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Terminals
Power (Watts) 18.00W
Voltage - Rated 115VAC
Additional Feature APPROVALS: UL; VDE
Power Rating 18W
Max Power Dissipation 18W
Depth 119mm
Frequency 60Hz
Voltage - Rated AC 115V
Approval Agency CE, CSA, UL, VDE
Operating Supply Voltage 115V
Lifetime @ Temp 40000 Hrs @ 40°C
Life (Hours) 40000 hours
RPM 3100 RPM
Hole Diameter 4 mm
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 106.0 CFM (2.97m3/min)
Power Consumption 18W
Noise 51.0 dB(A)
Outside Diameter 119 mm
Thermal Support Device Type AC FAN
Life Expectancy 15000 h
Dimensions
Height 38mm
Thickness 38mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
