19028527A
RoHS
/
Package Axial
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 119X39MM 115VAC MX2A4
PDF
/
Buying Options
Total Price: USD $28.49
Unit Price: USD $28.4944
≥1 USD $28.4944
≥10 USD $21.49004
≥100 USD $19.701
Inventory: 211
Minimum: 1
-
+
Technical Details
Physical
Package / Case Axial
Material - Frame Magnesium Alloy
Material - Blade Magnesium Alloy
Technical
Operating Temperature -18.4~158°F -28°C~70°C
Published 2010
Series Muffin XL AC
Size / Dimension Square - 119mm Lx119mm H
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Max Operating Temperature 158°C
Min Operating Temperature -18.4°C
Power (Watts) 15.00W
Voltage - Rated 115VAC
Current Rating (Amps) 0.180A
Max Power Dissipation 15W
Current Rating 180mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 55000 Hrs @ 40°C
Life (Hours) 55000 hours
RPM 3100 RPM
Bearing Type Sleeve
Fan Type Tubeaxial
Air Flow 115.0 CFM (3.22m3/min)
Noise 50.0 dB(A)
Dimensions
Width 39.00mm
Compliance
RoHS Status RoHS Compliant
