19028312A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 171.5X50.8MM PT77B3
PDF
/
Inventory: 126
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Package / Case Axial
Weight 1.8lbs 816.5g
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2012
Series Patriot AC
Size / Dimension Round - 171.5mm Dia
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Terminals
Power (Watts) 30.00W
Voltage - Rated 230VAC
Additional Feature PERMANENT SPLIT CAPACITOR MOTOR, HALF SPEED IMPEDANCE PROTECTION
Current Rating (Amps) 0.140A
Max Power Dissipation 30W
Reach Compliance Code unknown
Current Rating 140mA
Approval Agency CE, cUL, UL
Lifetime @ Temp 65000 Hrs @ 30°C
Life (Hours) 65000 hours
RPM 3400 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 235.0 CFM (6.58m3/min)
Noise 54.0 dB(A)
Static Pressure 0.772 in H2O (192.3 Pa)
Thermal Support Device Type AC FAN
Dimensions
Diameter 171.5mm
Width 50.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
