19028029A
RoHS
/
Package Axial
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 120X38MM 230VAC MU3B1
PDF
/
Inventory: 9540
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Axial
Weight 1.1lbs 499.0g
Technical
Published 2006
Series Muffin AC
Size / Dimension Square - 120mm Lx120mm H
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Terminals
Power (Watts) 14.00W
Voltage - Rated 230VAC
Current Rating (Amps) 0.090A
Max Power Dissipation 14W
Current Rating 90mA
RPM 3100 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 102.0 CFM (2.86m3/min)
Noise 45.1 dB(A)
Static Pressure 0.296 in H2O (73.7 Pa)
Dimensions
Width 38.00mm
Compliance
RoHS Status RoHS Compliant
