17000540A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 80X25MM CR8025EC-4500
PDF
/
Buying Options
Total Price: USD $56.27
Unit Price: USD $56.269626
≥1 USD $56.269626
≥10 USD $53.084555
≥100 USD $50.079765
≥500 USD $47.245064
≥1000 USD $44.570814
Inventory: 1330
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Weight 0.386lb 175.09g
Material - Frame Magnesium Alloy
Material - Blade Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Technical
Operating Temperature -4~158°F -20°C~70°C
Published 2016
Size / Dimension Square - 80mm Lx80mm H
Feature Auto Restart, Electronic Commutation (EC)
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Terminals
Power (Watts) 4.00W
Voltage - Rated 100V~240VAC
Current Rating (Amps) 0.480A
Approval Agency CE, cUL, UL
Lifetime @ Temp Varies Based on Temperature
RPM 4500 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 32.0 CFM (0.896m3/min)
Noise 45.0 dB(A)
Voltage Range 90V~264VAC
Static Pressure 0.360 in H2O (89.6 Pa)
Dimensions
Width 25.00mm
Compliance
RoHS Status ROHS3 Compliant
