17000537A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 120X25MM CR1225EC-3200
PDF
/
Buying Options
Total Price: USD $45.68
Unit Price: USD $45.6808
≥1 USD $45.6808
≥10 USD $42.48992
≥100 USD $38.24099
≥500 USD $35.054272
≥1000 USD $32.929688
≥3000 USD $28.680749
Inventory: 166
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Static Pressure 0.300 in H2O (74.7 Pa)
Voltage Range 90V~264VAC
Noise 47.0 dB(A)
Air Flow 92.0 CFM (2.58m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3200 RPM
Lifetime @ Temp Varies Based on Temperature
Approval Agency CE, cUL, UL
Current Rating (Amps) 0.700A
Voltage - Rated 100V~240VAC
Power (Watts) 5.50W
Termination 2 Terminals
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Auto Restart, Electronic Commutation (EC)
Size / Dimension Square - 120mm Lx120mm H
Published 2016
Operating Temperature -4~158°F -20°C~70°C
Physical
Material - Blade Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material - Frame Magnesium Alloy
Weight 0.498lb 225.89g
Supply Chain
Factory Lead Time 18 Weeks
