AHM150PS15
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
XP POWER AHM150PS15AC/DC Power Supply, Medical, Mains Plug Sold Separately, 80 V, 264 V, 150 W, 15 V, 10 A
PDF
/
Buying Options
Total Price: USD $117.98
Unit Price: USD $117.978
≥1 USD $117.978
≥10 USD $111.3
≥100 USD $105
≥1000 USD $93.44963
Inventory: 5072
Minimum: 1
-
+
Technical Details
Physical
Mount External
Weight 1.3lbs 589.7g
Technical
Operating Temperature 0°C~60°C
Published 2011
Series AHM150 (150W)
Size / Dimension 7.80Lx3.15W x 1.45 H 200.0mmx80.0mmx37.0mm
Part Status Discontinued
Moisture Sensitivity Level (MSL) Not Applicable
Applications ITE (Commercial), Medical
Power Rating 150W
Max Power Dissipation 150W
Number of Outputs 1
Approval Agency CB, TUV, UL
Efficiency Level V
Lead Length 900mm
Max Output Current 10A
Voltage - Output 1 15V
Voltage - Input 80V~264VAC
Output Current 10A
Input Type Cord (Sold Separately)
Output Power 150W
Min Input Voltage 80V
Max Input Voltage 264V
Current - Output 1 10A
Max Output Power 150W
Form Desktop (Class I)
Region Utilized International
Cord Length 35.4 0.9m
Input Connector IEC 320-C14
Output Connector Power DIN, 4 Pin
Nominal Output Voltage 15V
No Load Power Consumption 500mW Max
Min Input Voltage (AC) 80V
Max Input Voltage (AC) 264V
Dimensions
Height 36.83mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
