AEL40US48
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC DESKTOP ADAPTER 48V 40W
PDF
/
Inventory: 5251
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 52.07mm
Length 118.11mm
Height 34.544mm
Technical
No Load Power Consumption 500mW Max
Output Connector Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 11.0mm
Input Connector IEC 320-C14
Cord Length 48 1.22m
Region Utilized International
Form Desktop (Class I)
Voltage - Output 48V
Output Power 40W
Input Type Cord (Sold Separately)
Output Current 830mA
Voltage - Input 90V~264VAC
Current - Output (Max) 830mA
Polarization Positive Center
Polarity Positive
Max Output Current 830mA
Efficiency Level V
Approval Agency CB, TUV, UL
Max Power Dissipation 40W
Power Rating 40W
Power (Watts) 40W
Applications ITE (Commercial)
Min Operating Temperature -20°C
Max Operating Temperature 60°C
Connector Type Plug
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Discontinued
Size / Dimension 4.65Lx2.05W x 1.36 H 118.0mmx52.0mmx34.5mm
Series AEL40 (40W)
Published 2011
Operating Temperature -20°C~60°C
Physical
Weight 0.64lb 290.3g
Mount Plug-In
