AEL20US15
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC DESKTOP ADAPTER 15V 20W
PDF
/
Inventory: 6379
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 41.91mm
Length 99.06mm
Height 30.988mm
Technical
No Load Power Consumption 500mW Max
Output Connector Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 11.0mm
Input Connector IEC 320-C6
Cord Length 48 1.22m
Region Utilized International
Form Desktop (Class I)
Voltage - Output 15V
Output Power 20W
Input Type Cord (Sold Separately)
Output Current 1.33A
Voltage - Input 90V~264VAC
Current - Output (Max) 1.33A
Polarization Positive Center
Polarity Positive
Max Output Current 1.33A
Efficiency Level V
Approval Agency CB, TUV, UL
Max Power Dissipation 20W
Power Rating 20W
Power (Watts) 20W
Applications ITE (Commercial)
Min Operating Temperature -20°C
Max Operating Temperature 60°C
Connector Type Plug
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Discontinued
Size / Dimension 3.90Lx1.65W x 1.22 H 99.0mmx42.0mmx31.0mm
Series AEL20 (20W)
Published 2011
Operating Temperature -20°C~60°C
Physical
Weight 0.375lb 170.1g
Mount Desktop
