AEH80UM31
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
XP POWER AEH80UM31AC/DC Power Supply, Desktop, Mains Plug Sold Separately, Fixed, 65W, 5V, 6A, 12V, 3A, -12V, 800mA
PDF
/
Buying Options
Total Price: USD $123
Unit Price: USD $123
≥1 USD $123
≥10 USD $116.03774
≥100 USD $109.46956
Inventory: 1601
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Current - Output 3 800mA
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 12V
Current - Output 2 3A
Nominal Output Voltage -12V
Output Connector DIN, 8 Pin
Input Connector IEC 320-C14
Cord Length 48 1.22m
Region Utilized International
Form Desktop (Class I)
Max Output Power 65W
Voltage - Output 3 -12V
Current - Output 1 6A
Max Input Voltage 264V
Min Input Voltage 90V
Voltage - Output 2 12V
Voltage - Output 5V 12V -12V
Output Power 65W
Input Type Cord (Sold Separately)
Output Current 6A
Voltage - Input 90V~264VAC
Current - Output (Max) 6A 3A 800mA
Voltage - Output 1 5V
Max Output Current 3A
Lead Length 1.22m
Efficiency 80%
Approval Agency CE, cUL
Number of Outputs 3
Power Rating 65W
Power (Watts) 76W
Applications ITE (Commercial)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 6.61Lx3.09W x 1.75 H 167.9mmx78.5mmx44.5mm
Series AEH80 (80W)
Published 2012
Operating Temperature 0°C~60°C
Physical
Number of Pins 8
Supply Chain
Factory Lead Time 19 Weeks
