SMI6-5-K-P5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC WALL MOUNT ADAPTER 5V 6W
PDF
/
Inventory: 7964
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Weight 0.212lb 96.16g
Technical
Operating Temperature 0°C~40°C
Published 2016
Series SMI6 (6W)
Size / Dimension 2.52Lx1.59W x 1.18 H 64.0mmx40.5mmx30.0mm
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) Not Applicable
Connector Type Plug
Max Operating Temperature 40°C
Min Operating Temperature 0°C
Applications ITE (Commercial)
Power (Watts) 6W
Max Power Dissipation 6W
Approval Agency CCC, CE, cULus, GS, PSE, RCM
Efficiency Level VI, CoC Tier 2
Max Output Current 1.2A
Polarity Positive
Polarization Positive Center
Current - Output (Max) 1.2A
Voltage - Input 90V~264VAC
Input Type Multi-Blade (Sold Separately)
Voltage - Output 5V
Form Wall Mount (Class II)
Region Utilized International
Cord Length 60.2 1.53m
Input Connector Multi-Blade
Output Connector Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 9.5mm
No Load Power Consumption 100mW Max
Dimensions
Height 29.972mm
Length 64.008mm
Width 40.386mm
Compliance
RoHS Status RoHS Compliant
