SDI18-5-UC-P5R
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC DESKTOP ADAPTER 5V 15W
PDF
/
Inventory: 9066
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Weight 0.319lb 144.7g
Technical
Operating Temperature 0°C~40°C
Published 2016
Series SDI18-U (18W)
Size / Dimension 3.94Lx1.97W x 1.30 H 100.0mmx50.0mmx33.0mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Connector Type Plug
Max Operating Temperature 40°C
Min Operating Temperature 0°C
Applications ITE (Commercial)
Power (Watts) 15W
Max Power Dissipation 18W
Approval Agency CE, cULus, NEMKOgs, PSE
Efficiency Level VI, CoC Tier 2
Max Output Current 3A
Polarity Positive
Polarization Positive Center
Current - Output (Max) 3A
Voltage - Input 90V~264VAC
Input Type Cord
Voltage - Output 5V
Form Desktop (Class I)
Region Utilized North America
Cord Length 59 1.50m
Input Connector IEC 320-C14
Output Connector Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 9.5mm
No Load Power Consumption 100mW Max
Dimensions
Height 33.02mm
Length 100.076mm
Width 50.038mm
Compliance
RoHS Status RoHS Compliant
