DTS240083UDC-P13P
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC DESKTOP ADAPTER 24V 20W
PDF
/
Inventory: 6491
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Desktop
Technical
Operating Temperature 10°C~40°C
Published 2002
Size / Dimension 3.54Lx2.28W x 1.10 H 90.0mmx58.0mmx28.0mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Connector Type Plug
Applications ITE (Commercial)
Max Power Dissipation 20W
Efficiency 70%
Max Output Current 830mA
Polarity Positive
Polarization Positive Center
Voltage - Input 90V~264VAC
Output Current 830mA
Input Type Cord
Output Power 20W
Voltage - Output 24V
Form Desktop (Class II)
Cord Length 72 1.83m
Input Connector IEC 320-C8
Output Connector Barrel Plug, 1.7mm I.D. x 4.0mm O.D. x 9.5mm
Dimensions
Height 27.94mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
