DTS090166UDC-P14/RN
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC DESKTOP ADAPTER 9V 15W
PDF
/
Inventory: 998
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Desktop
Technical
Operating Temperature 10°C~40°C
Published 2002
Size / Dimension 3.54Lx2.28W x 1.10 H 90.0mmx58.0mmx28.0mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Connector Type Plug
Max Operating Temperature 40°C
Min Operating Temperature 10°C
Applications ITE (Commercial)
Power (Watts) 15W
Max Power Dissipation 15W
Efficiency 65%
Max Output Current 1.66A
Polarity Negative
Polarization Negative Center
Current - Output (Max) 1.66A
Voltage - Input 90V~264VAC
Output Current 1.66A
Input Type Cord
Output Power 14W
Voltage - Output 9V
Form Desktop (Class II)
Cord Length 72 1.83m
Input Connector IEC 320-C8
Output Connector Barrel Plug R/A, 1.7mm I.D. x 4.8mm O.D. x 9.5mm
Dimensions
Height 27.94mm
Length 89.916mm
Width 57.912mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
