DTS050250SUDC-P14N
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC DESKTOP ADAPTER 5V 13W
PDF
/
Inventory: 8214
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Desktop
Weight 0.516lb 234.05g
Technical
Operating Temperature 0°C~40°C
Published 2002
Size / Dimension 2.91Lx1.81W x 0.98 H 74.0mmx46.0mmx25.0mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Connector Type Plug
Max Operating Temperature 40°C
Min Operating Temperature 0°C
Applications ITE (Commercial)
Power (Watts) 13W
Max Power Dissipation 13W
Efficiency 65%
Max Output Current 2.5A
Polarity Negative
Polarization Negative Center
Current - Output (Max) 2.5A
Voltage - Input 90V~264VAC
Output Current 2.5A
Input Type Cord
Output Power 12.5W
Voltage - Output 5V
Form Desktop (Class II)
Cord Length 72 1.83m
Input Connector IEC 320-C8
Output Connector Barrel Plug, 1.7mm I.D. x 4.8mm O.D. x 9.5mm
Dimensions
Height 24.892mm
Length 73.914mm
Width 45.974mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
