DTS050240U/AC1-P14N
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC DESKTOP ADAPTER 5V 12W
PDF
/
Inventory: 7333
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Desktop
Weight 234g
Technical
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Connector Type Plug
Applications ITE (Commercial)
Power (Watts) 12W
Max Power Dissipation 12W
Number of Outputs 1
Max Output Current 2.4A
Polarity Negative
Polarization Negative Center
Current - Output (Max) 2.4A
Voltage - Input 100V~240VAC
Cable Length 1.83m
Output Current 2.4A
Input Type Cord
Output Power 12W
Voltage - Output 5V
Form Desktop (Class II)
Cord Length 72 1.83m
Input Connector IEC 320-C8
Output Connector Barrel Plug, 1.7mm I.D. x 4.8mm O.D. x 9.5mm
Dimensions
Height 25.5mm
Length 74mm
Width 46mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
