DPD060025-P5P-DK
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC WALL MOUNT ADAPTER 6V 3W
PDF
/
Inventory: 2919
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Wall
Technical
Size / Dimension 2.33Lx1.50W x 1.35 H 59.2mmx38.0mmx34.2mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Connector Type Plug
Applications ITE (Commercial)
Power (Watts) 3W
Max Power Dissipation 3W
Number of Outputs 1
Approval Agency cULus
Max Output Current 500mA
Polarity Positive
Polarization Positive Center
Voltage - Input 120VAC
Output Current 250mA
Input Type Fixed Blade
Output Power 1.5W
Voltage - Output 6V
Form Wall Mount (Class II)
Region Utilized North America
Cord Length 72 1.83m
Input Connector NEMA 1-15P
Output Connector Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 9.5mm
Dimensions
Height 34.29mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
