SDS120PT15B

XP Power
RoHS
/
Package 120
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description XP POWER SDS120PT15B AC/DC Open Frame Power Supply, Fixed, 3 Output, 90 V, 260 V, 120 W, 5 V
PDF
/
Buying Options
Total Price: USD $186.56
Unit Price: USD $186.56
≥1 USD $186.56
≥10 USD $176
≥100 USD $166.03774
≥1000 USD $147.77299
Inventory: 4286
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Width 81.4mm
Length 127mm
Height 39.2mm

Technical

Current - Output 3 800mA
Max Input Voltage (AC) 260V
Min Input Voltage (AC) 90V
Current - Output 2 3.5A
Minimum Load Required Yes
Max Output Power 120W
Voltage - Output 3 12V
Current - Output 1 15A
Max Input Voltage 260V
Min Input Voltage 90V
Voltage - Output 2 24V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 120W
Output Current 15A
Voltage - Input 90V~264VAC
Current - Output (Max) 15A 3.5A 800mA
Output Voltage 5V
Voltage - Isolation 3000V
Efficiency 80%
Approval Agency cUL
Number of Outputs 3
Power Rating 120W
Subcategory Power Supply Modules
Applications ITE (Commercial)
Type Open Frame
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Adjustable Output, DC Input Capable, PFC, Universal Input
Series SDS (120W)
Published 2010
Operating Temperature 0°C~70°C With Derating

Physical

Package / Case 120
Mounting Type Chassis Mount

Supply Chain

Factory Lead Time 19 Weeks
