LCL500PS15
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 15V 500W
PDF
/
Inventory: 3867
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 250mm
Height 53mm
Technical
Ripple Voltage (Main Out) 0.05303Vrms
Nominal Output Voltage 15V
Minimum Load Required No
Max Output Power 500W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL
Output Power 510W
Output Current 34A
Voltage - Input 85V~264VAC
Max Output Current 34A
Output Voltage 15V
Voltage - Isolation 3kV
Efficiency 88%
Approval Agency CSA, EN, UL
Number of Outputs 1
Max Power Dissipation 500W
Power Rating 500W
Subcategory Power Supply Modules
Additional Feature REMOTE SHUTDOWN
Applications ITE (Commercial)
Type Enclosed
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, Remote On/Off, Remote Sense, Universal Input
Size / Dimension 9.84Lx5.00W x 2.08 H 250.0mmx127.0mmx53.0mm
Series LCL (500W)
Published 2009
Operating Temperature -10°C~70°C With Derating
Physical
Mounting Type Chassis Mount
Mount Chassis Mount, Panel
Supply Chain
Factory Lead Time 24 Weeks
