LCL300PS48
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER LCL300PS48 AC/DC Enclosed Power Supply, Industrial, Fixed, 1 Outputs, 85 V, 264 V, 320 W, 48 V
PDF
/
Inventory: 2281
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Technical
Operating Temperature -10°C~70°C With Derating
Published 2009
Series LCL (300W)
Size / Dimension 8.07Lx4.33W x 1.97 H 205.0mmx110.0mmx50.0mm
Feature Adjustable Output, Universal Input
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Applications ITE (Commercial)
Subcategory Power Supply Modules
Power Rating 320W
Max Power Dissipation 300W
Number of Outputs 1
Approval Agency CSA, EN, UL
Efficiency 88%
Voltage - Isolation 3kV
Output Voltage 48V
Max Output Current 6.7A
Voltage - Input 85V~264VAC 127V~370VDC
Output Current 6.7A
Output Power 322W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL
Min Input Voltage 85V
Max Input Voltage 264V
Current - Output 1 6.7A
Max Output Power 320W
Minimum Load Required No
Nominal Output Voltage 48V
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 264V
Dimensions
Height 50mm
Length 205mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
