JPS130PS05-M
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER JPS130PS05-M AC/DC Open Frame Power Supply, Medical, Fixed, 1 Output, 90 V, 264 V, 130 W, 5 V
PDF
/
Buying Options
Total Price: USD $143
Unit Price: USD $143
≥1 USD $143
≥10 USD $134.90566
≥100 USD $127.26949
Inventory: 7075
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Height 32.4mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 90V
Input Current 2.6A
Nominal Output Voltage 5V
Minimum Load Required No
Max Output Power 130W
Current - Output 1 20A
Max Input Voltage 264V
Min Input Voltage 90V
Output Power 130W
Output Current 20A
Voltage - Input 90V~264VAC
Max Output Current 20A
Output Voltage 5V
Voltage - Isolation 4000V
Efficiency 90%
Approval Agency CE
Number of Outputs 1
Frequency 63Hz
Power Rating 130W
Power (Watts) 100W 130W Forced Air
Applications Medical
Type Open Frame
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input
Size / Dimension 5.00Lx3.00W x 1.18 H 127.0mmx76.2mmx30.0mm
Series JPS (130W)
Published 2012
Operating Temperature 0°C~70°C With Derating
Physical
Mounting Type Chassis Mount
