HPU1K5PS48
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER HPU1K5PS48 AC/DC Enclosed Power Supply, Medical, Adjustable, 1 Outputs, 85 V, 264 V, 1.5 kW, 48 V
PDF
/
Buying Options
Total Price: USD $1060.37
Unit Price: USD $1060.367
≥1 USD $1060.367
≥10 USD $1025.5
≥25 USD $1018.3714
≥50 USD $1011.29235
Inventory: 78
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Technical
Operating Temperature -20°C~70°C With Derating
Published 2009
Series HPU1K5 (1500W)
Size / Dimension 12.75Lx4.00W x 1.70 H 323.9mmx101.6mmx43.2mm
Feature Adjustable Output, Remote Sense, Standby Output, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 1500W
Additional Feature REMOTE SHUTDOWN
Subcategory Power Supply Modules
Power Rating 1.5kW
Max Power Dissipation 1.5kW
Number of Outputs 1
Approval Agency CSA, EN, UL
Efficiency 90%
Voltage - Isolation 4kV
Output Voltage 48V
Max Output Current 25A
Voltage - Input 85V~264VAC
Output Current 31A
Output Power 1.493kW
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL
Min Input Voltage 85V
Max Input Voltage 264V
Current - Output 1 31A
Max Output Power 1.5kW
Minimum Load Required No
Nominal Output Voltage 48V
Current - Output 2 1A
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 264V
Dimensions
Height 43.2mm
Length 323.9mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
