HDS3000PS36
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
POWER SUPPLY, AC-DC, 36V, 83.5A
PDF
/
Buying Options
Total Price: USD $1507
Unit Price: USD $1507
≥1 USD $1507
≥10 USD $1457.44681
≥50 USD $1437.25482
≥100 USD $1407.69326
Inventory: 8312
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 27 Weeks
Physical
Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Package / Case 100
Technical
Operating Temperature -20°C~60°C With Derating
Published 2008
Series HDS3000 (3000W)
Size / Dimension 14.41Lx5.00W x 5.00 H 366.0mmx127.0mmx127.0mm
Feature Adjustable Output, I2C? Interface, Load Sharing, Remote On/Off, Remote Sense, Standby Output, Universal Input
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 3000W
Max Power Dissipation 3kW
Number of Outputs 1
Approval Agency CB, TUV, UL
Efficiency 92%
Voltage - Isolation 3kV
Max Output Current 83.5A
Voltage - Input 90V~264VAC
Output Power 3.006kW
Min Input Voltage 90V
Max Input Voltage 264V
Current - Output 1 83.5A
Max Output Power 3kW
Minimum Load Required No
Nominal Output Voltage 36V
Min Input Voltage (AC) 90V
Max Input Voltage (AC) 264V
Dimensions
Height 127mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
