EML30US24-E
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
XP POWER EML30US24-EAC/DC PCB Mount Power Supply, Medical, Fixed, 85 V, 264 V, 30 W, 24 V, 1.25 A
PDF
/
Buying Options
Total Price: USD $55
Unit Price: USD $55
≥1 USD $55
≥10 USD $51.88679
≥100 USD $48.9498
≥500 USD $46.17906
≥1000 USD $43.56515
≥3000 USD $41.0992
Inventory: 135
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 4-DIP Module
Weight 0.35lb 158.76g
Technical
Operating Temperature -20°C~70°C With Derating
Published 2012
Series EML30 (30W)
Size / Dimension 3.10Lx1.50W x 1.10 H 78.7mmx38.1mmx27.9mm
Feature OCP, OVP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Applications Medical
Max Power Dissipation 30W
Depth 78.7mm
Number of Outputs 1
Approval Agency CB, TUV, UL
Efficiency 82%
Max Output Current 1.25A
Voltage - Input 85V~264VAC
Output Power 30W
Min Input Voltage 85V
Max Input Voltage 264V
Current - Output 1 1.25A
Max Output Power 30W
Nominal Output Voltage 24V
Line Regulation ±0.5%
Load Regulation ±1%
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 264V
Dimensions
Height 27.9mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
